DC POE injector Procet Industrial Fiber PoE injector Output 44-57Vdc with waterproof case
Froducts Features:
Procet Industrial Din-rail Fiber 60W PoE injector,Input 44-57Vdc,Output 44-57Vdc, Surge Protection 6Kv, Working Temperature at -40℃ to 65℃
1. PT-PSE105GW-D is a single port midspan Injector with 4 Pair PoE up to 60 watts of power with 6Kv surge protection.
2. Designed for the PoE++ powered 60W PoE Powered Devices (PDs), such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks, It supports 10/100/1000Mbps of data rates. Fully comply with IEEE802.3Bt and remains compatible with any IEEE802.3af/at compliant devices. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non PoE device.
3. Enclosed in an IP40 high-impact metal case with DIN Rail mount bracket, designed for indoor use but can work outdoor by covered with waterproof case. It works with a wide input voltage of 44-57Vdc, the output voltage follows input and operates under -40℃ to +65℃, For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables
| key features | DIN Rail mount |
| Ports conditions | LAN Port*1, PoE Output Port*1, DC input Terminal Block*1 |
| User output power | 60W garantee |
| DC input voltage | 44-57Vdc |
| Reculatory compliance | RoHS IEEE802.3at WEEE |
Order Info.
PT-PSE105GW-D 48Vdc/0.32A/1000Mbps/(4,5+,7,8-)/Active
Packing
PT-PSE105GW-D x 1
Manual x 1
Stock Quantity
50PCS
Warehouse Location
Dongguan China
Sample Delivery Time
Within 24H
Bulk Stock Delivery Time
Within 48H
Shipping Way
DHL,UPS,FedEx,TNT,
By SEA/AIR
Customer Nominated Forwarder
Packing Size
Qty: 20pcs/carton
G.W.: 12Kgs
Volume: 0.03 m³
Packing: Export Carton
Pallet size: 110 x 110cm
